3C-C.L.O.M.E.A. Bending Machines

J&S Machine carries a full line of 3C-C.L.O.M.E.A. bending machines capable of covering the many needs of the bending industry.

The 3C-C.L.O.M.E.A. product line includes a variety of machines used to bend window and storefront extrusions, angle iron, tube and pipe, and a variety of other materials. To do this, 3C-C.L.O.M.E.A. has developed a complete line of hydraulic and electromechanical machines. With the application of several control options available, 3C-C.L.O.M.E.A. has a bending machine to fit your bending needs.

CRM Series

The CRM Series of machines from 3C-C.L.O.M.E.A. are open-ended roll bending machines with three drive rollers. The central roller is hydraulically positioned to achieve a desired radius. The machine housing and frame are constructed of heavy G30 cast iron mounted on an electro welded sheet metal base, accurately machined, and painted with a high-grade industrial paint. All the shafts, gears, and pinions are constructed of nickel chromium steel that is heat-treated and ground, mounted in grease lubricated dynamic tapered bearings designed for heavy-duty loads. All models in the CRM Series is capable of operating on both a horizontal and vertical bending plane.

CR Series

The CR Series of machines from 3C-C.L.O.M.E.A. are high performance hydraulic machines for bending steel and aluminum sections. The outer rollers are hydraulically positioned to achieve the desired radius. The machine housing and frame are made of heavy G30 cast iron and are electro welded onto a sheet metal base. All of the shafts, gears, and pinions are constructed of nickel chromium steel that is heat-treated and ground, mounted in grease lubricated dynamic tapered bearings designed for heavy-duty loads. All three rollers of these machines are driven to give them ample power to pull material through the bend. The CR13-R to CR24-R models can be operated in both the horizontal and vertical position.

Machine Specifications

Dimensions (LxWxH)
Vertical
Horizontal
30" x 36" x 63"
30" x 63" x 44"
38" x 47" x 48"
48" x 38" x 46"
41" x 57" x 65"
41" x 65" x 57"
48" x 38" x 46"
44" x 38" x 59"
48" x 38" x 46"
44" x 38" x 59"
Weight 775 lbs. 1170 lbs. 1765 lbs. 1170 lbs. 1170 lbs.
Shaft Diameter ø30mm ø50mm ø60mm ø50mm ø50mm
Rotation Motor 1½ HP 4 HP 5½ HP 3 HP 3 HP
Central Hydraulic Motor 1½ HP, 100 Bar 5? HP, 180 Bar 5½ HP, 180 Bar 3 HP, 110 Bar 3 HP, 145 Bar
Rotation Speed (RPM)
Single Speed
Two Speed
Variable Speed

NA
6 - 12
10
3½ | 7
1½ - 8½
7
3½ | 7
1½ - 8½
10
5 | 10
2½ - 12
10
5 | 10
2½ - 12
Dimensions (LxWxH)
Vertical
Horizontal
50" x 38" x 48"
48" x 38" x 61"
50" x 44" x 50"
50" x 44" x 61"
NA
111" x 87" x 60"
NA
111" x 87" x 61"
Weight 2120 lbs. 2250 lbs. 7060 lbs. 7280 lbs.
Shaft Diameter ø60mm ø70mm ø100mm ø120mm
Rotation Motor 4 HP 5½ HP 13¾ HP 13¾ HP
Central Hydraulic Motor 5½ HP, 150 Bar 7½ HP, 190 Bar 7? HP, 160 Bar
12¼ HP, 160 Bar
7? HP, 160 Bar
12¼ HP, 200 Bar
Rotation Speed (RPM)
Single Speed
Two Speed
Variable Speed
7
3½ | 7
1½ - 8½
7
3½ | 7
1½ - 8½
6
3 | 6
NA
6
3 | 6
NA
